Epson EB-805F 5000lms Ultra-short Throw Full HD Laser Projector

Epson EB-805F 5000lms Ultra-short Throw Full HD Laser Projector

EPSON
SKU:
V11H923652

Pricing available upon request

Warranty: 3yrs Parts & Labor Carry- In for Projector Main Unit
Current Stock:
Description
Create Your Own Customer Experience.

Wow your customers and strengthen marketing messages with Epson EB-805F Full HD1 ultra-short throw laser projector! Create stunning video content easily and instantly project your information wirelessly to your audience. EB-800 series projectors’ laser light source allows it to be placed in any orientation, even in tight spaces, and are the ideal companion for your digital signage needs.



Remarkable Image Quality
With an optimum brightness of 5,000 lumens and dynamic contrast of over 2,5000,000:1, be assured that your images will be vivid and attention-grabbing even under a variety of ambient lightings. The ultra-short-throw laser projector is able to project beautiful and sharp images even in the tightest retail spaces up to a maximum of 130-inch.



Multi-directional Projection
Thanks to its laser light source, EB-800 series projectors can rotate 360° in any direction — horizontally, vertically and rotationally — without any loss in image brightness and quality. An ideal companion to businesses that require vivid projections on a variety of surfaces such as floors and ceilings.




Flexible Projection Images
The black background in images will not be projected on surface, allowing non-rectangular images. This allows flexibility and great creativity in creating content. Thus, this gives users the ability to form sleek and eye-catching designs, without being confined to a rectangular image.




Do-It-Yourself Content
Create video and image content with Epson Creative Projection App*. With over 40 high quality templates to choose from, customise stunning and creative content effortlessly and project them wirelessly to capture your audience’s attention. What’s more, the app is totally free and easily downloadable from Apple App Store!

*Epson Creative Projection App is currently available on iOS only.



Technical Specifications
  • Projectors Facets:
    • Resolution, Projectors Facets: 1080p
    • Contrast Ratio, Projectors Facets: Over 2,500,000:1
    • Inputs & Interfaces, Projectors Facets:
      • HDMI
      • Epson Creative Projection App
      • RJ-45 & RS-232
      • USB Plug and Play
    • Brightness Range Lumens, Projectors Facets: 4001
    • Features, Projectors Facets:
      • Quick Corner
      • Ultra Short Throw
      • Edge Blending
    • Laser / Lamp, Projectors Facets: Laser
  • Projection Technology: RGB liquid crystal shutter projection system
  • Connectivity:
    • Network:
      • Wireless LAN: 1 x USB Type A (In common with Memory I/O)
      • Wired LAN: RJ45 x 1
    • Analog Input:
      • Composite: RCA x 1 (Yellow)
      • D-Sub 15Pin: 2
    • Digital Input:
      • HDMI: 3 (HDCP2.3)
      • HDBaseT: 1 (HDCP2.3)
    • Audio Input: Stereo Mini Jack: 3
    • Audio Output: Stereo Mini Jack: 1
    • Control I/O: RS-232C: D-sub 9 pin x 1
    • Others:
      • USB Type B: 1 (for USB Display, mouse, K/B, Control, Firmware Update, Interactive, Copy OSD Settings)
      • USB Type A: 2 (for Saving and Reading* data via USB Memory, USB Document Camera)
  • Contrast Ratio: Over 2,500,000:1
  • Wireless Specifications (Wireless LAN: Built-in):
    • Supported Speed for Each Mode:
      • Infrastructure: IEEE 802.11b (2.4GHz): 11 Mbps*2, IEEE 802.11g (2.4GHz): 54 Mbps*2, IEEE 802.11n
      • (2.4GHz): 72.2 Mbps*2, IEEE 802.11a (5GHz): 54 Mbps*2, IEEE 802.11n (5GHz): 150 Mbps*2, IEEE 802.11ac
      • (5GHz): 325 Mbps*2
      • Access Point (Wi-Fi Direct): IEEE 802.11g (2.4GHz): 54 Mbps*2, IEEE 802.11n (2.4GHz): 72.2 Mbps*2, IEEE
      • 802.11a (5GHz): 54 Mbps*2, IEEE 802.11n (5GHz): 150 Mbps*2, IEEE 802.11ac (5GHz): 325 Mbps*2
    • Wireless LAN Security:
      • Infrastructure: OPEN, WPA2/WPA3-PSK, WPA2/WPA3-EAP
      • Supported EAP Type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
      • Access Point (Wi-Fi Direct): WPA2-PSK(AES)
    • Supported Connection Mode: Infrastructure, Access Point (Wi-Fi Direct)
  • Screen Size (Projected Distance):
    • Standard Size: 80” [48.7 cm]
    • Zoom : Wide:
      • 65” – 130” [39.2 – 80.3 cm] @ 16:9
      • 61” – 120” [39.5 – 79.6 cm] @ 16:6
    • Zoom : Tele: 48” – 96” [39.2 – 80.3 cm] @ 16:9
  • Geometric Correction:
    • Vertical/Horizontal Keystone: ±3° / ±3°
    • Quick Corner: Yes
  • Operating Temperature:
    • Single Use: 0 - 45 °C <41 - 113 °F> [20% – 80% Humidity, No Condensation]
    • Multi-projection Use: 0 - 40 °C <41 - 104 °F> [20% – 80% Humidity, No Condensation]
  • Start-Up Period: Less than 8 - 10 seconds (Epson Logo), Warm-up Period: 30 seconds
  • Cool Down Period: Instant Off
  • Internal Speaker(s):
    • Sound Output: 8W x 8W [Stereo]
  • Direct Power On/Off: Yes
  • Dimension Excluding Feet (W x H x D): 458 x 209.5 x 375 mm
  • Weight:
    • Approx. 9.4 kg (Without Cable Cover)
    • Approx. 9.7 kg (With Cable Cover)
  • Air Filter:
    • Maintenance Cycle: 20,000 hours*3
  • Fan Noise:
    • Normal / Quiet: 36dB / 27dB
  • Specifications of Main Parts:
    • LCD:
      • Native Resolution: Full HD (1080p)
      • Size: 0.62” (C2Fine)
    • Lightsource:
      • Type: Laser Diode
      • Life (Normal / Extended): 20,000 / 30,000 hours
    • Projection Lens:
      • Type: Focus (Manual) / No Optical Zoom
      • F-Number: 1.50
      • Focal Length: 3.90 mm
      • Zoom Ratio: 1 – 1.35 (Digital Zoom)
      • Throw Ratio: 0.27 – 0.37 (Wide to Tele)
  • Power Consumption (220 - 240V):
    • Laser Diode ON (Normal / Extended): 366W / 262W
    • Networked Standby / Energy Saving: 2.0W / 0.5 W

What's Included

  • Power Cable: 1.8m x 1
  • Remote Control with 2x AA Battery
  • Cable cover
  • Foot for main unit
  • Lens cap
Additional Information
ANSI (Lumens):
5000
Resolution:
Full HD (1920 x 1080)
Product Type:
Projector
