Kramer OSP-SM10 Optical SM 1310nm 10G SFP+ Transceiver

OSP−SM10 is a fiber optic transceiver for 1310nm single−mode signals. This standard pluggable SFP+ module has two LC connectors for reception and transmission signals over two strands of single−mode optical fiber.

•  Certified Transceiver — Kramer certified, hot–pluggable SFP+ optical module, for high–quality transmission of 10.2Gbps signal over single–mode fiber cables, connecting 2 simplex single–mode fiber strands via LC AP/UPC connectors.

Key Features

• Certified SFP+ optical module
• 2–strand LC–connected single–mode fiber
• Ultra–reach — Up to 33km (20.5 miles)
• 2 single–mode LC strands
• Data rate — 10.2Gbps

Technical Specifications

• Optical Line: Single–mode G.652D compliant OFNR fiber
• Ports:

  • 2–strand fiber optic LC(PC/UPC) connector for reception and transmission SFP+ compliant pluggable interface
  • Note: Do not use with LC(APC) connectors
• Max. Reach: 33Km (20.5 miles) reach over OS1 SM fiber
• Nominal Peak Wavelength: 1310nm
• Max. Data Rate: 10.2Gbps
• Transmitter Type: DFB
• Optical Typical Transmission Power: –2.5dBm
• Optical Typical Maximum Receiver Sensitivity: –14.4dBm
• Optical Typical Maximum Loss Budget: 11.9dB
• Standards Compliance: IEEE 802.3ae, SFF–8431
• Laser Safety Compliance: Laser Class I
• Regulatory Certifications: FDA CDRH 21 CFR 1040 and Laser Notice No. 50, UL and CUL EN60950–2:2007, RoHS6, EMC EN 55022 and EN 55024, IEC 62368–1 and IEC 60825–1 and — 2
• Power Consumption: 1W
• Operating Temperature: 0° to 70°C
• Storage Temperature: –40° to 85°C
• Humidity: 5% to 95% RH
• Product Dimensions: 1.33cm x 5.70cm x 0.85cm (0.52" x 2.24" x 0.33" ) W, D, H
• Shipping Dimensions: 12.60cm x 8.40cm x 4.10cm (4.96" x 3.31" x 1.61" ) W, D, H
• Shipping Weight: 0.1kg (0.1lbs) approx.
