Kramer SFP1-MM-D Optical Multi–Mode 850nm 1G SFP Transceiver

SFP1−MM−D is a fiber optic duplex transceiver for 850nm multimode signals. This standard pluggable SFP optical module has an LC connector for reception and transmission of signals over a single strand of multimode optical fiber.

•  Certified Transceiver — Kramer certified, hot–pluggable SFP optical module, for high–quality transmission of 1.25Gbps signal over multimode fiber cables, connecting 2 multimode fiber strands via LC AP/UPC connectors.

Key Features

• Certified SFP optical module
• 1–strand LC–connected multimode fiber
• Ultra–reach — Up to 10km (6.2 miles)
• Data rate — 1.25Gbps

Technical Specifications

• Optical Line: Multi–mode G.651.1 compliant OFNR fiber
• Ports:

  • 2–strand duplex fiber optic LC (PC/UPC) connector
  • Note: Do not use with LC (APC) cable connectors
• Max. Reach: 10km (6.2 miles) over OM3 SM fiber
• Nominal Peak Wavelength: 850nm
• Max. Data Rate: 1.25Gbps
• Transmitter Type: VCSEL
• Optical Typical Transmission Power: –9.5dBm
• Optical Typical Maximum Receiver Sensitivity: –17dBm
• Optical Typical Maximum Loss Budget: 14dB
• Standards Compliance:
  • IEEE 802.3z
  • SFP MSA
• Laser Safety Compliance: Laser Class I
• Regulatory Certifications:

  • TUV R50135086
  • UL E317337
  • EMC CE AE 50384190 0001
  • FCC WTF14F05144170000E
• Operating Temperature: 0° to 70°C
• Storage Temperature: –40° to 85°C
• Humidity: 0% to 95% RH
• Product Dimensions: 1.33cm x 5.70cm x 0.85cm (0.52" x 2.24" x 0.33" ) W, D, H
• Shipping Dimensions: 12.60cm x 8.40cm x 4.10cm (4.96" x 3.31" x 1.61" ) W, D, H
• Shipping Weight: 0.1kg (0.1lbs) approx.
