Verkada Outdoor Directional Wi-Fi Antenna for GW Series, N-Type

The Outdoor Directional Wi-Fi Antenna can improve signal strength on the GW31-E when pointed toward the correct Wi-Fi access point. For optimal performance, mount the antenna such that there's a clear line of sight toward the access point.

Technical Specifications

• Cable Length: 100cm / 39"
• Frequency Range:

  • 2.4 - 2.5 GHz
  • 5.15 - 5.85 GHz
• Weight: 1.4kg / 3.0lbs
• Peak Gain (Per Range):

  • 11.4 dBi
  • 13.2 dBi
• Dimensions:

  • Length: 300mm / 11.8"
  • Width: 200mm / 7.9"
  • Height: 110mm / 4.3"
• Polarization: Vertical / Horizontal
• Operating Temperature Range: -30°C to 70°C / -22°F to 158°F
• Peak Beamwidth:
  • Horizontal: 68°, Vertical: 25°
  • Horizontal: 61°, Vertical: 13°
• Mounting Options:

  • Wall or pole mounting
  • Pole straps (3 - 4" diameter)
  • #8 wall screws with drywall anchors included
• Connectors: 2x N-Type male plugs
