MAXHUB LX108V07R All-In-One Interactive Touch LED Display 108"

MAXHUB LX108V07R All-In-One Interactive Touch LED Display 108"

MAXHUB
SKU:
LX108V07R

Pricing available upon request

Current Stock:
Description

Experience more than just a display; with numerous built-in applications, transform your room into a versatile space. With high compatibility, this optional built-in PC is compatible with a variety of devices and protocols needed for different display scenarios. The system supports a range of platforms such as Teams, Zoom, Webex, and Google Meet. Featuring Wake on Sync and Microsoft Teams Rooms PC wake-on with Raptor, this system allows for effortless preparation of your meeting room, freeing your hands for other tasks.

Technical Specfications

  • LED type: SMD
  • Size: 108"
  • Aspect Ratio: 16:9
  • Pixel Pitch(mm): 1.25
  • Resolution: 1920x1080
  • Overall Size (L*H)(mm): 2432 x 1492
  • Screen Thickness: 28 mm
  • Weight: 80kg
  • Recommended Viewing Distance: =2.8 m(9.19 ft.)
  • Maintenance Mode: Front Access
  • Installation Mode: Mobile stand, Stand, Wall-mounting
  • Operation Voltage: 100~240VAC 50/60Hz
  • Standby Power: =0.5W
  • Sound Channel: 4.2
  • Speaker Output: 4*30W
  • Operating System: Android 13.0
  • CPU: Four Cortex-A76+ four Cortex-A55, frequency 2.4GHz
  • RAM: 8GB
  • Storage: 64GB
  • Media Format:
    • Support mainstream video format such as MPEG-1,MPEG-2,MPEG-4,H.263,H.264, H.265,VC-1,VP9,VP8,MVC,AV1
    • Support audio formats such as MP3; Support JPG, JPEG, BMP, PNG, GIF and other image format.
  • Operation Temperature: -10?~40?
  • Operation Humidity: 10%~80%RH No condensation
  • HDMI IN(HDMI2.0 *1,HDMI1.4 *3): 4 (2 internal, 2 external)
  • HDMI OUT: 1 (external)
  • POE: 1 (internal) - Up to 30W
  • USB 2.0: 1 (internal) - Host
  • USB 3.0: 2 (external) - Host
  • Type C: 1 (external)
  • 3.5 Audio Output: 2 (1 internal, 1 external)
  • 3.5 Audio Input: 1 (external)
  • RS232(RJ45): 1 (internal)
  • USB Out: 1 (external) - After connecting to a PC, the PC can access the LED front USB port.
  • LAN: 2 (internal)
  • Light Sensor: 1: intelligent space sensing, allowing for automatic brightness adjustment
  • Bluetooth: 5.3
  • Wi-Fi: WiFi 6, AP and STA modes, and WiFi 6 dual-band 2.4G/5G are available
Additional Information
Meeting Room Size:
Medium
Meeting Room Size:
Large
Resolution:
HD - 1080p
Screen Size:
108"
Product Type:
Video Conferencing
Product Type:
Display
