Netgear 8-Port 10G Multi-Gigabit Ethernet Smart Switch with SFP+
NetgearPricing available upon request
Lifetime Warranty
Expand your business's network to support high-bandwidth applications with the Netgear MS510TXM 8-Port Multi-Gigabit Managed Switch. This eight-port managed switch includes four 2.5G Ethernet ports alongside four 10G Ethernet ports for high-volume data transfers with compatible devices such as computers and network storage drives. Two 10G SFP+ ports are also available for high-speed fiber uplinks and device connections. Equipped with a 1 GHz dual-core processor with 256MB of memory and featuring a 140 Gb/s switching capacity and 14.8 Mpps forwarding rate, this switch delivers fast and reliable performance. With three cooling fans, the MS510TXM is designed to operate quietly in a desktop or rackmount installation. Activating the included 1-year Netgear Insight Cloud Management platform subscription allows you to configure, manage, and monitor connected devices using powerful Layer 2+ and Layer 3 Lite features from almost anywhere in the world.
Netgear Insight Cloud Management Features
- Remote monitoring and management features with performance dashboards and troubleshooting capabilities.
- Multi-device, multi-network, and multi-site remote monitoring and notifications using the Netgear Insight app.
- The Netgear Insight Cloud Portal enables local or remote access for configuration, management, and monitoring using a tablet, laptop, or desktop computer.
- Configurable in-app and email alerts and notifications
- Zero-touch provisioning allows you to quickly add and configure additional Insight Managed devices added to the network.
- Centralized network policies across Insight managed switches, access points, network storage devices, and more.
- Cloud-based network administration, monitoring, and firmware management.
Key Features
- 4 x 2.5G Ethernet Ports
- 4 x 10G Ethernet Ports
- 2 x 10G SFP+ Ports
- 140 Gb/s Switching Capacity
- 14.8 Mpps Forwarding Rate
- 1 GHz Dual-Core CPU | 256MB RAM
- Desktop & Rack Mountable Design
- Netgear Insight Cloud Management Support
Technical Specifications
- Multi-gigabit copper ports: 4 (1G/2.5G)
- Multi-gigabit/10 Gigabit copper ports: 4 (1G/2.5G/5G/10G)
- SFP+ ports: 2
- Max MAC entries: 32K
- Buffer size: 16Mbit
- VLAN (Number Supported): 256
- VLAN routing: Yes
- Dynamic VLAN assignment: Yes
- MLD Snooping: Yes
- Static route: Yes (32)
- Host ARP table: 512 ARP
- EEE: Yes
- DoS Prevention: Yes
- Internal/External PSU: Internal
- Max power (worst case, all ports used, line-rate traffic): 47W
- Fans: 2
- Acoustic Noise Level @25C: 25.0 dBA
- Operating Temperature: 0 to 50C (32 to 122F)
- MTBF: 1,059,519 hrs (121 yrs)
- Dimensions (W x D x H): 330 x 206 x 43 mm ( 13.0 x 8.12 x 1.7 in)
- Weight: 2.08 kg (4.25 lb)
